Case Phanteks NV Series NV7 TG DRGB

GENERAL

Case Dimensions

253 x 532 x 586 mm | 10.0 x 20.9 x 23.1 in

Form Factor

Full Tower

Mainboard Support

E-ATX | ATX | Micro-ATX | Mini-ITX

Materials

Steel chassis | Tempered glass

Color

Matte White

PCI Slots

8

Vertical GPU Support

3 slots

Internal 2.5″ Bay

6 (+ 1x 3.5″ HDD)

Internal 3.5″ Bay

2 (+ 2x 2.5″ SSD)

Front I/O

2x USB 3.0 USB-C Gen2

Microphone | Headphone Combo

Power Button

D-RGB Mode Button

D-RGB Color Button

D-RGB Speed Button

D-RGB Channel Button

FANS (120 | 140)

Total Fans

12x | 3x

Top

3x | -

Front

-

Side

4x | -

Rear

2x | -

Bottom

3x | 3x

RADIATOR (120 | 140)

Top

Max. 360 | -

Front

-

Side

Max. 360 | -

Rear

120 | -

Bottom

Max. 360 | 280

CLEARANCE

CPU Cooler

185 mm | 7.28 in

GPU

450 mm | 17.71 in

Power Supply (Length)

255 mm | 10.03 in

Top Radiator (L x W)

132 x 440 mm | 5.19 x 17.32 in

Side Radiator (L x W)

132 x 440 x 65 mm | 5.19 x 17.32 x 2.55 in

Rear Radiator (L x W)

132 x 320 mm | 5.19 x 12.59 in

EXTRA

Net Weight

16.90 kg | 37.25 lbs

Gross Weight

19.70 kg | 43.43 lbs

Screws

34x Mainboard | SSD screws

4x Power supply screws

4x Thumb screws

12x Case screws

9x HDD screws

1x Motherboard stand-off

1x Stand-off removal tool

1x Extra R-side panel screw
